Pallet Size Guide
The definitive reference for pallet dimensions, weight capacities, and sizing standards used across every major logistics market worldwide.
Need Pallets in a Specific Size?
Tell us the dimensions and quantities you need. We stock all standard sizes and build custom pallets to order.
Why Pallet Size Matters for Your Business
Choosing the correct pallet size is one of the most impactful decisions in supply chain management. The right pallet dimensions directly affect how efficiently you use warehouse floor space, how many units you can load into a truck or container, and how safely your goods travel from origin to destination. A mismatch of even a few inches can cascade into thousands of dollars in wasted space, damaged products, and higher freight costs over the course of a year.
In North America, the 48×40-inch GMA pallet dominates grocery, retail, and general merchandise distribution because it was specifically engineered to maximize a standard 53-foot trailer. A single trailer can hold 20 GMA pallets on the floor when loaded two-deep, and racking systems across the continent are built to accommodate those dimensions. Switching to an oddball size means your pallets may not fit existing racking, conveyor systems, or automated pallet jacks, and you will lose negotiating power with carriers who price based on standard footprints.
Internationally, the picture is more complex. European logistics are built around the 1200×800 mm EUR 1 pallet, while Australia standardizes on 1165×1165 mm. Asian markets use a mix of 1100×1100 mm and 1200×1000 mm footprints. If you export goods, you need to match the pallet standard of your destination market or risk rejection at the dock, additional handling fees, or product damage caused by overhang and underhang.
Weight capacity is equally critical. Every pallet has two load ratings: a dynamic load (the maximum weight it can carry while being moved by a forklift or pallet jack) and a static load (the maximum weight it can bear while sitting stationary on a warehouse floor or in racking). Overloading a pallet beyond its rated capacity leads to deck board failure, collapsed stacks, and workplace injuries. Under-specifying capacity wastes money on unnecessarily heavy or expensive pallets.
At SD Re Pallet, we help businesses throughout California select the optimal pallet size for every application. Whether you need thousands of standard GMA pallets for a distribution center, Euro pallets for an export program, or custom-dimensioned pallets for an unusual product, our team provides expert guidance backed by decades of experience in the pallet industry.
Comprehensive Pallet Size Quick-Reference Table
The master table below covers every major pallet size in use worldwide, from the most popular standards to industry-specific specialty sizes. Bookmark this table as your go-to reference.
| Name / Standard | Inches (L×W) | Millimeters (L×W) | Region | Dynamic Load | Static Load | Racking Load | Footprint (sq ft) |
|---|---|---|---|---|---|---|---|
| GMA / North American | 48 × 40 | 1219 × 1016 | USA / Canada | 2,800 lbs | 5,500 lbs | 2,500 lbs | 13.33 |
| EUR 1 (Euro Pallet) | 47.24 × 31.50 | 1200 × 800 | Europe | 3,307 lbs | 8,818 lbs | 2,205 lbs | 10.33 |
| EUR 2 | 47.24 × 39.37 | 1200 × 1000 | Europe / Asia | 2,756 lbs | 8,818 lbs | 2,205 lbs | 12.92 |
| EUR 3 | 39.37 × 47.24 | 1000 × 1200 | Europe | 3,307 lbs | 8,818 lbs | 2,205 lbs | 12.92 |
| EUR 4 (Half Euro) | 31.50 × 23.62 | 800 × 600 | Europe | 1,102 lbs | 2,954 lbs | — | 5.17 |
| EUR 5 (Quarter Euro) | 23.62 × 15.75 | 600 × 400 | Europe | 551 lbs | 1,102 lbs | — | 2.58 |
| EUR 6 | 31.50 × 23.62 | 800 × 600 | Europe | 1,102 lbs | 4,409 lbs | 1,102 lbs | 5.17 |
| Australian Standard | 45.87 × 45.87 | 1165 × 1165 | Australia / NZ | 4,600 lbs | 8,800 lbs | 3,500 lbs | 14.61 |
| Asia T11 | 43.30 × 43.30 | 1100 × 1100 | Japan / Korea / China | 2,200 lbs | 4,400 lbs | 1,800 lbs | 13.02 |
| China GB/T 2934 | 44.88 × 44.88 | 1140 × 1140 | China (domestic) | 2,200 lbs | 4,400 lbs | 1,800 lbs | 13.97 |
| Drum Pallet | 42 × 42 | 1067 × 1067 | Global | 2,500 lbs | 5,000 lbs | 2,000 lbs | 12.25 |
| Half Pallet (US) | 48 × 20 | 1219 × 508 | USA (Retail) | 1,400 lbs | 2,800 lbs | — | 6.67 |
| Quarter Pallet (US) | 24 × 20 | 610 × 508 | USA (Display) | 700 lbs | 1,500 lbs | — | 3.33 |
| Chemical / Pharma | 48 × 42 | 1219 × 1067 | USA | 3,000 lbs | 6,000 lbs | 2,500 lbs | 14.00 |
| Military (40×48) | 40 × 48 | 1016 × 1219 | USA | 2,800 lbs | 5,500 lbs | 2,500 lbs | 13.33 |
| Beverage (36×36) | 36 × 36 | 914 × 914 | USA | 2,000 lbs | 4,000 lbs | 1,600 lbs | 9.00 |
| Automotive (48×45) | 48 × 45 | 1219 × 1143 | USA | 3,000 lbs | 6,000 lbs | 2,500 lbs | 15.00 |
| Oversize (60×48) | 60 × 48 | 1524 × 1219 | USA | 4,000 lbs | 8,000 lbs | 3,000 lbs | 20.00 |
| Sheet Goods (96×48) | 96 × 48 | 2438 × 1219 | USA | 6,000 lbs | 12,000 lbs | — | 32.00 |
Dynamic load ratings assume a standard hardwood pallet in good condition. Actual capacity varies with wood species, moisture content, and pallet grade. See our grading guide for details.
Weight Capacity Overview: Static vs. Dynamic vs. Racking
Understanding the three types of pallet load ratings is essential for safety and cost optimization. Each rating reflects a different stress condition, and the same pallet will have a different maximum weight for each scenario.
Dynamic Load Capacity
The maximum weight a pallet can carry while being lifted and moved by a forklift or pallet jack. This is the most commonly referenced rating because most pallets spend the majority of their life being transported. Dynamic loads introduce shock forces, vibration, and uneven weight distribution that stress the pallet structure more than stationary storage.
Typical range: 1,000 - 4,600 lbs
Static Load Capacity
The maximum weight a pallet can support while sitting on a flat, solid surface such as a warehouse floor. Because there is no movement, shock, or vibration, static capacity is typically 1.5 to 2.5 times the dynamic rating. Static loads assume the weight is evenly distributed across the deck surface. Concentrated or uneven loads reduce the effective static capacity.
Typical range: 2,000 - 12,000 lbs
Racking Load Capacity
The maximum weight a pallet can support when placed on warehouse racking beams with its edges supported but its center span unsupported. This creates bending stress across the pallet, making racking load the most demanding condition. Racking capacity is typically 60-75% of dynamic capacity and depends heavily on the span distance between rack beams.
Typical range: 800 - 3,500 lbs
Which Pallet Size Is Best for Your Industry?
Different industries have converged on specific pallet sizes based on product dimensions, weight requirements, regulatory mandates, and supply chain compatibility. Use this table to find the recommended starting point for your sector.
| Industry | Recommended Size | Why This Size | Typical Weight Per Load |
|---|---|---|---|
| Grocery / Retail | 48 × 40 (GMA) | Required by all major retailers; optimizes 53' trailers | 1,800 - 2,500 lbs |
| Pharmaceutical | 48 × 40 or 48 × 42 | Clean room compatibility; often requires Grade A and HT stamp | 800 - 1,500 lbs |
| Chemical / Drums | 42 × 42 or 48 × 48 | Fits four 55-gallon drums perfectly in a 2×2 arrangement | 1,800 - 2,400 lbs |
| Automotive | 48 × 45 or 56 × 44 | Sized for auto parts bins and assembly line flow racks | 2,000 - 3,000 lbs |
| Beverage | 48 × 40 or 48 × 36 | Heavy concentrated loads; often double-stacked | 2,200 - 2,800 lbs |
| European Export | 1200 × 800 (EUR 1) | Required by European warehouses and the EPAL exchange pool | 1,500 - 2,500 lbs |
| Asian Export | 1100 × 1100 (T11) | Standard across Japan, Korea; growing in China and SE Asia | 1,200 - 2,000 lbs |
| Building Materials | 48 × 40 or 96 × 48 | Standard for retail distribution; oversized for sheet goods | 2,500 - 5,000 lbs |
| E-Commerce Fulfillment | 48 × 40 (GMA) | Amazon, Walmart.com, and major 3PLs mandate GMA dimensions | 1,200 - 2,200 lbs |
| Retail Display | 48 × 20 (Half) or 24 × 20 (Quarter) | Fits in store aisles; rolls directly to sales floor on display carts | 400 - 1,200 lbs |
| Agriculture / Produce | 48 × 40 or 40 × 40 | Cold storage compatible; used for bins and crates | 1,500 - 2,500 lbs |
| Aerospace | Custom or 72 × 48 | Oversized components; air-freight size requirements | 1,000 - 4,500 lbs |
The 5 Most Popular Pallet Sizes and Their Use Cases
While dozens of pallet sizes exist, these five account for over 80% of all pallets in circulation worldwide. Understanding the specific strengths of each will help you make the right choice.
48 × 40 GMA Pallet
The undisputed king of North American logistics. Approximately 2 billion GMA pallets are in circulation in the U.S. alone, accounting for 30% of new pallet production. Every major retailer, grocery distributor, and 3PL provider in North America designs their operations around this size. Twenty pallets fit on the floor of a standard 53-foot trailer, and virtually all racking systems, conveyors, and automated handling equipment are built to accommodate the 48×40 footprint.
Best for: Domestic U.S./Canada distribution, grocery, retail, CPG, pharmaceutical, e-commerce fulfillment
EUR 1 Euro Pallet (1200 × 800 mm)
The backbone of European logistics with an estimated 500-600 million pallets in the EPAL pool. The EUR 1 is a nine-block pallet that provides true four-way forklift entry and operates within a formalized exchange pool where pallets can be swapped one-for-one at any transfer point. Its smaller footprint compared to the GMA pallet allows 26 units per trailer floor, but each pallet carries less product. The strict EPAL licensing and audit system ensures consistent quality across manufacturers in over 30 countries.
Best for: European distribution, export to EU/UK, EPAL exchange pool participants, operations requiring block pallet 4-way entry
Australian Standard (1165 × 1165 mm)
Australia’s square pallet is the largest of the major international standards at 14.61 sq ft, and it boasts the highest dynamic load capacity at 4,600 lbs. Managed primarily through the CHEP pooling system, the Australian pallet is engineered for the country’s unique supply chain, where heavy loads of produce, beverages, and building materials travel long distances over rough roads. The square shape allows loading from any orientation, and the robust nine-block construction handles the extreme demands of Australian logistics.
Best for: Export to Australia/New Zealand, heavy-duty applications, CHEP pool participants
Asia T11 (1100 × 1100 mm)
The dominant pallet in Japan and Korea, with rapidly growing adoption across China, Taiwan, and Southeast Asia. The T11 designation comes from the Japanese standard JIS Z 0604. Its 1100×1100 mm square footprint optimizes the internal width of standard ISO shipping containers, making it particularly efficient for ocean freight. The Asian Pallet Pool System (APPS) is expanding to create a EPAL-style exchange pool across the region. T11 pallets are typically lighter than their Western counterparts, built with softwood or engineered materials to reduce shipping weight.
Best for: Export to Japan/Korea/China, ocean container optimization, light-to-medium weight loads
Drum Pallet (42 × 42)
Specifically designed to hold four standard 55-gallon drums in a 2×2 arrangement with minimal wasted space. The 42×42 footprint provides just enough support for the drum diameters (approximately 22.5 inches each) while fitting efficiently into standard trailers. This size is widely used in the chemical, petroleum, food ingredient, and paint industries. Many 42×42 pallets are built with flush decks (no gaps between boards) to contain spills and prevent drums from shifting during transport.
Best for: Chemical drums, paint, petroleum products, bulk liquid containers, telecommunications equipment
Container & Trailer Loading Optimization Tips
Maximizing the number of pallets that fit inside a truck trailer or shipping container is one of the fastest ways to reduce per-unit freight costs. The internal dimensions of common transport vessels are fixed, but the pallet size you choose determines how efficiently you fill that space. Below are practical optimization strategies organized by container type.
53-Foot Dry Van Trailer (Internal: 630″ L × 100.5″ W × 110″ H)
- GMA 48×40: Load 20 pallets on the floor (two columns of 10, each two-deep). With product height under 48 inches, you can double-stack for 40 pallets per load. Floor utilization: approximately 88%.
- EUR 1 (1200×800): Load 26 pallets on the floor using a pinwheel pattern (alternating orientation). Floor utilization: approximately 86%. The smaller footprint means more handling at the dock but more pallets per truck.
- 48×48 or 42×42: These square sizes leave gaps in standard trailers. Consider alternating orientations or mixing with narrower pallets to fill dead space. A 42×42 loads 20 on the floor but wastes approximately 14% of floor space.
- Tip: Always load the heaviest pallets at the front (near the cab) and distribute weight evenly side to side. Unbalanced loads cause trailer sway and increase the risk of rollovers.
20-Foot ISO Container (Internal: 233″ L × 92.1″ W × 89.8″ H)
- GMA 48×40: 10 pallets (two rows of five, turned 40″ into the container width). Floor utilization: approximately 79%. The 1.3-inch gap on each side prevents tight fits.
- EUR 1 (1200×800): 11 pallets using alternating orientation. Floor utilization: approximately 83%. Euro pallets are specifically designed to optimize European ISO container dimensions.
- T11 (1100×1100): 10 pallets (two rows of five). Floor utilization: approximately 88%. The T11 was engineered to tile ISO containers efficiently.
- Tip: For ocean freight, consider container-optimized pallet sizes. A custom 44×44 or 46×46 pallet may yield 10-15% more product per container compared to standard sizes, saving thousands per shipment on high-volume lanes.
40-Foot ISO Container (Internal: 474″ L × 92.1″ W × 89.8″ H)
- GMA 48×40: 20 pallets (two rows of 10). Same loading pattern as a 53' trailer but narrower. Floor utilization: approximately 82%.
- EUR 1 (1200×800): 23-24 pallets using pinwheel loading. The most container-efficient of the major Western standards.
- T11 (1100×1100): 20 pallets (two rows of 10). Floor utilization: approximately 90%. The best single-size option for 40' container optimization.
- Tip: High-cube (HC) 40' containers add 12 inches of headroom (102″ internal height). Use this extra height to add an additional layer of product per pallet or to stack pallets higher. The floor pallet count remains the same.
Loading Optimization Calculator
Not sure which pallet size maximizes your specific container or trailer? Our logistics team can run a loading optimization analysis for your product dimensions and shipping lanes. We use professional pallet loading software that calculates the optimal pallet size, loading pattern, and orientation to minimize wasted space and freight cost.
Request a Free Loading AnalysisExplore Our Complete Size Guides
Standard Pallet Sizes
Complete chart of all standard pallet sizes worldwide, including dimensions in inches and millimeters, weight capacities, and typical applications.
View guide →GMA Pallets (48x40)
Everything you need to know about the 48x40 GMA pallet — the most widely used pallet in North America, including specs, history, and industry usage.
View guide →Euro Pallets (EPAL)
Full specifications for EUR 1 through EUR 6 pallets, certification requirements, and how European pallet standards compare to North American ones.
View guide →Custom Pallet Sizes
When standard sizes do not fit your needs, learn how to design custom pallets optimized for your product dimensions, weight, and logistics workflow.
View guide →Size Comparison Chart
Side-by-side comparison of every major pallet standard worldwide — GMA, Euro, Australian, Asian, and more — with visual size references and use cases.
View guide →How to Choose the Right Pallet Size
1. Measure Your Product
Start with the dimensions of the unit load you plan to palletize. The ideal pallet should be slightly larger than your product footprint to prevent overhang (which causes damage during transport) while minimizing underhang (which wastes trailer space). A 1-2 inch margin on each side is standard practice.
2. Know Your Logistics
Consider your trailer or container dimensions, rack beam spacing, and conveyor widths. If your pallets move through automated systems, dimensional accuracy is critical. A pallet that is even half an inch too wide can jam an automated storage and retrieval system.
3. Calculate Weight
Add up the total weight of your product plus packaging per pallet load. Compare that number to both the dynamic and static load ratings. Always build in a safety margin of at least 20% to account for uneven loading and shock forces during transit.
4. Consider the Destination
If you ship domestically in North America, the 48×40 GMA pallet is almost always the right choice. For European exports, switch to EUR 1. For mixed markets, talk to our team about the most versatile option that works across your supply chain.
